HI1-0201HS-2 Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
- Description: QUAD SPST CMOS ANALOG SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HI1-0201HS-2 Specifications:
- MfrPart.: HI1-0201HS-2
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: QUAD SPST CMOS ANALOG SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 50Ohm
- Channel-to-ChannelMatching(ΔRon): 1.5Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 50ns, 50ns
- -3dbBandwidth: -
- ChargeInjection: 10pC
- ChannelCapacitance(CS(off)CD(off)): 10pF, 10pF
- Current-Leakage(IS(off))(Max): 10nA
- Crosstalk: -86dB @ 100kHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-CDIP (0.300, 7.62mm)
- HI1-0201HS-2 Maxim Integrated, QUAD SPST CMOS ANALOG SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
